ACF6000 Series uses the Coriolis effect as a technique for liquid mass flow measurement.
The ACF6000 can measure most of the liquids; the infrared light sensor makes it easy for you to set parameters & change the display data. The Double-C tube & Double-D Tube make it possible for the meter to be used in most liquid applications.
FEATURES
Can be programmed by infrared light sensor without opening cover
High turndown ratio of flow rate
It comes any flanges such as ANSI, DIN, JIS... etc
Excellent for high pressure application
Simple for installation, commission and maintenance
Self-diagnostic capabilities, cable faults, pipe vibration
High accuracy of +/-0.2% of reading (or +/-0.1% of reading)
With forward / reverse flow rate measurement function
SPECIFICATION
Sensor Type:C tube (10-40mm) / U tube (50-150mm)
Size:10mm ~ 200 mm (3/8'' ~ 8'')
Flow Range:0 - 1000 Kg/Hr ~ 0 - 1106000 Kg/Hr
Accuracy: +/-0.2% +/-ZS of reading (Standard)
+/-0.1% +/-ZS of reading (Optional)
Accurac:y+/-0.002 g/cm3
Temperature Range:-40 deg.C to +125 deg.C (Standard)
-40 deg.C to +250 deg.C (Optional, Separate Only)
Protection Class:IP 67/ Explosion Proof Exde (ib) IIC T6 (Optional)
Signal Cable Length:10M - 100M
Display:2 lines LCD with illumination
Flow Rate Unit:g/s, Kg/min, kg/Hr, T/Hr, 5 Digit
Communication:RS485 (Modbus Protocol)
Hart Signal (Optional)
Max. Pressure:63 Kg/cm2
http://www.alia-inc.com
